Application qualification
This page converts the SUS-A schema slots into a welding application workflow. It contains no sustainability claims: the subject is joint definition, coupon testing, parameter capture, document review, and production handoff.
Working declaration
We begin with the base metal, thickness, joint geometry, welding position, filler classification, shielding method, input power, duty demand, production fixture, inspection route, and applicable procedure. That dataset produces a candidate process window. It does not replace a WPS, procedure qualification record, operator qualification, current product manual, or authority having jurisdiction.
Where public evidence is limited, the correct response is a representative coupon and a documented review—not an invented certainty. The result records what was tested, how it was inspected, and which changes require a new check.
Three qualification targets
Use the production material specification, thickness or qualified range, preparation, backing, position, restraint, and access condition. A flat bead on plate cannot represent every groove, fillet, pipe, or out-of-position joint.
Capture voltage, current, wire-feed speed, travel speed, gas type and flow, polarity, electrode extension, torch angle, preheat, interpass temperature, cable length, and feeder configuration as applicable.
Agree before the trial whether evaluation is visual, dimensional, macroetch, bend, tensile, radiographic, ultrasonic, or another method. Record the code edition, acceptance criteria, sample identity, and instrument status.
Readiness ledger
These bars represent workflow gates, not corporate performance percentages. A gate closes only when the named artifact exists and its revision is recorded.
Verify procedure number, revision, essential variables, qualified range, and approval status.
Check the exact model, input requirement, output curve, duty-cycle condition, environmental rating, and maintenance limits.
Confirm classification, diameter, shielding gas, polarity, storage condition, lot control, and regional availability.
Record method, acceptance criteria, sample frequency, instrument identification, and responsible role.
Certification marks and code references vary by model and destination. Confirm the current declaration or listing for the shipped equipment. A badge on a webpage is not a substitute for the controlled document.
Attach the joint and process facts you already control. Missing facts will be identified as open gates so the trial plan remains transparent.
